Flat Bar
Solid rectangular aluminum bars for general fabrication, busbars, and structural trim.
We utilize high-grade 6063 Aluminum Alloy, valued for its exceptional shaping flexibility and high structural precision. This material is ideal for manufacturing complex profiles, ranging from thin-walled hollow sections to intricate solid shapes, while providing a superior surface finish for anodizing, polishing, and custom color coatings.
Aluminium-Magnesium-Silicon Alloy (AlMgSiO)
| %Cu | %Mn | %Mg | %Cr | %Zn | %Ti | %Other | %Aluminium |
|---|---|---|---|---|---|---|---|
| 0.10 | 0.10 | 0.35 - 0.55 | 0.05 | 0.10 | 0.10 | 0.05 | Remainder |
| Temper | Ultimate Tensile Strength (MPa) | 0.2% Proof Stress (MPa) | % Elongation |
|---|---|---|---|
| T4 | 130 | 69 | 14 |
| T5 | 150 | 110 | 7 |
| T6 | 185 | 160 | 7 |
Indicates the as-fabricated condition where control has been exercised over the temper of the alloy.
Indicates the heat treated alloy.
Solution heat treatment followed by natural ageing at room temperature to a substantial stable condition.
Artificial ageing after an elevated temperature, rapid cooling fabrication process such as casting or extrusion.
Solution heat treatment followed by artificial ageing.
Natural aluminium finish of the extrusion-press with no further anodizing or colouring process.
Note: For subsequent severe forming processes as in bending, please opt for softer tempers.
All specifications conform to international standards. Values shown are typical and may vary based on specific manufacturing processes and quality control requirements.
Profile catalogue
Explore the available profile shapes and open a profile to view its specifications.
Solid rectangular aluminum bars for general fabrication, busbars, and structural trim.
Solid square-section bars engineered for high-strength machining components and structural supports.
Solid cylindrical rods designed for precision CNC turning, shafts, and mechanical parts.
T-shaped structural extrusions ideal for joint reinforcement, panel edging, and architectural ceiling grids.
Standard L-shaped equal leg profiles for corner protection, structural framing, and brackets.
Heavy-duty L-shaped equal leg profiles engineered for specialized industrial loading and bracing.
